Bussmann's SC type fuses are UL Class G and provide fast-acting (1/2-6 A) and time-delay (7-60 A) characteristics for circuit protection need. SC fuses are size rejecting in terms of their overall length thereby aiding in the prevention of overfusing.

Specifications:

Type: Class CF, Class J
Characteristics: 10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Indicating
Voltage Rating: 600 Volt AC, 300 Volt DC
Current Rating: 100 Amp
Interrupting Rating: 300 Kiloamp (Symmetrical, UL), 200 Kiloamp (Symmetrical, CSA), 100 Kiloamp DC (UL, CSA)
Length: 3.01 Inch
Approval: UL, CSA, CE
