Eaton's residential CH circuit breakers provide premium overload protection. The Type CH circuit breakers trip to the OFF position, eliminating nuisance callbacks. The CHF family also includes a trip flag to differentiate between a trip and the breaker being turned off. The thermal-magnetic trip curve avoids nuisance tripping on mild overloads while reacting almost instantaneously to severe short-circuit conditions. Multiple breakers have an internal common trip connection to operate all poles simultaneously. Handles are marked with ON-OFF indication and ampere rating of the breaker.

Specifications:

Number of Poles: 3
Voltage Rating: 208 VAC Star/120 VAC
Current Rating: 200 Ampere
Interrupting Rating: 100 Kiloampere
Mounting: Bolt-On
Used On: 37 MM/37SS Series Modular Meter Stack
