Burndy K22A39U2 Mechanical Cable Terminal Lug

Out of stock
SKU: 103129
Regular price $163.58
OR

These Dual-Rated One-Conductor Lugs are Constructed from High Strength Aluminum Alloy and Electro-Tin Plated to Provide Low Contact Resistance; For Aluminum and Copper Conductors

Specifications:

Number of Conductors: 4
Minimum Conductor Size: 1/0 AWG Stranded
Maximum Conductor Size: 750 KCMIL Stranded
Conductor Material: Aluminum/Copper
Material: Electro-Tin Plated Aluminum Alloy
Number of Pad Holes: 2
Pad Size: 2.31 Inch L x 3.06 Inch W x 0.75 Inch Thk
Stud Size: 3/8 Inch
Overall Length: 4.91 Inch
Approval: UL 468-A, UL 468-B, CSA
