The six position RJ-11 style modular plug is traditionally used in voice/phone applications. Two versions are available: 6P6C (six position/six contact) and 6P4C (six position/four contact). The RJ-11 6P4C (four contacts) is used for 1 or 2 line phone systems common in residential systems. The RJ-12 6P6C (six contacts) is used for 1, 2, or 3 line systems and is found in more commercial systems. Modular plug connectors support the latest TIA/EIA standards for twisted pair cabling. IDEAL modular plugs are designed to work seamlessly with the IDEAL Telemaster series of modular plug crimp tools. Plugs are designed and manufactured to support all 100Ω cable wiring schemes.IDEAL modular plugs are manufactured to strict industry standards and tolerances that utilize traditional preparation and termination methods. These proven and preferred methods allow for improved compatibility among manufacturers and devices around the world without the need for special tooling or preparation methods and eliminate the risk of shorts and crosstalk often associated with open end or feed through type connectors.

Specifications:

Type: RJ11
Number of Positions: 6
Number of Pins: 4
Cable Type: Round/Flat, Category 3/5E
Conductor Size: 24 AWG Solid/Stranded
Configuration: Standard
Contact Material: Gold Plated
Standard Package: 25 per Pack
