RoHS/Reach/WEEE Compliant

Specifications:

Number of Poles: 3
Power Rating/Voltage: 22 Kilowatt at 230 Volt/38 Kilowatt at 400 Volt/66 Kilowatt at 690 Volt (AC-1), 18.5 Kilowatt at 400 Volt (AC-2), 11 Kilowatt at 230 Volt/18.5 Kilowatt at 400 Volt/22 Kilowatt at 500 Volt/22 Kilowatt at 690 Volt (AC-3)
Current Rating: 60 Amp at 400/690 Volt/55 Amp at 690 Volt (AC-1), 40 Amp at 400 Volt/24 Amp at 690 Volt (AC-3), 35 Amp at 400 Volt (AC-4)
Coil Voltage: 220 Volt AC 50 Hertz, 240 Volt AC 60 Hertz
Mounting: 35 Millimeter Standard DIN Rail, Screw/Snap-On
Enclosure: IP00/20
Size: S2
Construction Standard: IEC
Approval: UL, EAC, CSA, CE, CCC
