Set Screw type transitional fitting ideal for commercial and institutional facilities. The 4157-DC is used to securely join EMT to two armored or metal clad cables and 3/8" flexible metal conduit. A labor savings, compared to the traditional junction box or fitting assembly installation. When using AC/MC/FMC cable simply remove the armor and expose the conductors to the desired length needed to reach the device box or enclosure. The inspection holes will provide a visual end stop for the cable or flex conduit. The use of anti short bushings is recommended. Tighten the steel strap screws between the armor convolutions, and compression nut for the 3/4" EMT conduit. Patented.

Specifications:

Installation: EMT to Flexible Metal Conduit/Duplex Armored/Metal Clad Cable
Trade Size: 3/4 Inch EMT Conduit x 3/8 Inch Flexible Metal Conduit, (2) 14 AWG to (3) 10 AWG
Material: Die Cast Zinc
Size: 2-3/8 Inch L x 1-3/4 Inch W
Standard Package: 100
Approval: UL (Canada and US), CSA C22.2
Used On: EMT/Flexible Metal Conduit
