Burndy YHD400 Compression Tap Connector

Wide Range, Universal and Reversible Figure H Shaped Aluminum Connector, Conductors are Separated by the Shape of the Connector, Bendable Tabs Secure both Run and Tap Conductors Freeing the Linemans Hands to Work with the Installation Tool, Massive Aluminum Design Minimizes Corrosion Due to Galvanic Corrosion, Pre-Filled with Penetrox Joint Compound and Individually Packaged, RoHS Compliant

Specifications:

Shape: H
Conductor Material: Copper/Aluminum/ACSR/AAAC/Steel
Minimum Run Conductor Size: 250 KCMIL Solid, 3/0 AWG Stranded, 3/0 AWG (ACSR), 3/0 AWG (Compact ACSR), 4/0 AWG (Compact Copper/Aluminum)
Maximum Run Conductor Size: 300 KCMIL Solid, 4/0 AWG Stranded, 4/0 AWG (ACSR), 266.8 KCMIL (Compact ACSR), 266 KCMIL (Compact Copper/Aluminum)
Minimum Tap Conductor Size: 250 KCMIL Solid, 3/0 AWG Stranded, 3/0 AWG (ACSR), 3/0 AWG (Compact ACSR), 4/0 AWG (Compact Copper/Aluminum)
Maximum Tap Conductor Size: 300 KCMIL Solid, 4/0 AWG Stranded, 4/0 AWG (ACSR), 266.8 AWG (Compact ACSR), 266 AWG (Compact Copper/Aluminum)
Die Index: D3
Body Material: Aluminum
Approval: RUS
