Horizontal or Vertical Mounting on Upright Panel for Application Freedom; Screw Type Power Terminals have Captive, Backed-Out Self-Lifting Pressure Plates with Screws—Reduced Wiring Time; Accessible Terminals for Easy Wiring. Optional Fingerproof Shields Available to Prevent Electrical Shock; Top Located Coil Terminals Convenient and Readily Accessible. 45 MM Contactor Magnet Coils have Three Terminals, Permitting Either Top or Diagonal Wiring—Easy to Replace European or U.S. Style Starters or Contactors without Changing Wiring Layout; Easy Coil Change and Inspectable/Replaceable Contacts

Specifications:

Type: Non-Reversing
Power Rating/Voltage: 5.5 KW at 220 V 3 Phase, 11 KW at 380/415/440 V 3 Phase, 15 KW at 500/550 V 3 Phase, 7.5 KW at 660 V 3 Phase, 2 HP at 115 V 1 Phase, 3 HP at 230 V 1 Phase, 5 HP at 208 V 3 Phase, 7-1/2 HP at 240 V 3 Phase, 15 HP at 480 V 3 Phase, 20 HP at 600 V 3 Phase
Current Rating: 25 Ampere (UL), 32 Ampere (IEC Thermal Current)
Phase: 1 or 3
Coil Voltage: 110 VAC at 50 Hz, 120 VAC at 60 Hz
Auxiliary Contact: 1NO Right Mount
Size: IEC E
Enclosure Type: Open, DIN Rail Mount
Overloads: Bi-Metallic Ambient Compensated 1NO-1NC Automatic/Manual Reset Class 10/20
Construction Standard: IEC
