Manufactured from Seamless Tubing Provides a High Quality Design with No Seams to Split; Electrolytic Copper Provides Maximum Conductivity, Low Resistance and Ductility for Excellent Crimp Forming Properties; Electro-Tin Plated; Provides Durable Long Lasting Resistance to Corrosion; Positive Center Wire Stops Provides Proper Depth of Wire Insertion; Marked with Wire Size Provides Easy Wire Size Identification; RoHS Compliant

Specifications:

Type: Butt, Short-Barrel
Voltage Rating: 600 V
Length: 1.53 Inch
Conductor Size: 1/0 AWG Solid/Stranded (Copper), 1/0 AWG (Aircraft)
Insulation Type: Non-Insulated
Material: Seamless Electrolytic Tin Plated Copper
Approval: UL, CSA
