RoHS Compliant

Specifications:

Type: Molded Case, MD Frame
Voltage Rating: 600 Volt AC, 500 Volt DC
Maximum AC Voltage Rating (V): 600 V
Maximum DC Voltage Rating (V): 500 V
Current Rating: 500 to 800 Amp
Number of Poles: 3
Interrupting Rating: 100 Kiloamp at 240 Volt AC (UL), 65 Kiloamp at 480 Volt AC (UL), 50 Kiloamp at 600 Volt AC/500 Volt DC (UL), 100 Kiloamp at 220/240 Volt AC at 50/60 Hertz (IEC), 65 Kiloamp at 380/415 Volt AC at 50/60 Hertz (IEC)
Terminal Type: Line/Load Lug
Size: 16 Inch L x 9 Inch W x 6 Inch D
