Scheduling 56 on and Off Set Points Provide Individual Programs for Each Day of the Week; Minimum Setting is 1 Minute; Light Level Activation Turn on is User Settable from 1 to 100 Footcandle; Turn Off is a Maximum of 2 Times Turn on Level; Each Channel has an Independent Setting; Includes a User Settable Delay before on and Off Between 1 to 90 Seconds; Remote Override on Each Channel has Independent Input for a Maintained Dry-Contact Closure; May Use Tork Model SS410 and Trp-24B for Timed Override; May Use with Occupancy Sensor with Dry Contacts as Override; Manual Override Until the Next Regularly Scheduled ON or OFF, Automatic Operation then Resumes; Momentary Contact DGUM100A 2 Second Contact Closure on and Off to Control Mechanically Held Contactors or Latching Relays; Block Holiday 9 Holiday Blocks can be Set for Individual Days or for Duration of any Number of Days; Daylight Saving Automatic Adjustment; Leap Year Automatic Compensation; Clock Format; Power Outage Backup Permanent Schedule Retention; Supercapacitor Provides 7 Days of Real Time Backup; Enhanced Switching Inrush Current Limiting Technology Protects Relay Contacts for Extended Life with Zero Cross Type Switching

Specifications:

Type: 365/7 Day
Maximum Number of Operations: 56 per Day
Number of Circuits: 1
Switch Type: DPDT
Current Rating: 20 Amp at 24 to 277 Volt AC (Resistive, NO), 10 Amp at 24 to 277 Volt AC (Resistive, NC), 20 Amp at 120/277 Volt AC (Ballast, NO), 10 Amp at 120/277 Volt AC (Ballast, NC), 15 Amp at 120 Volt AC (Tungsten, NO)
Voltage Rating: 120 to 277 Volt AC at 50/60 Hertz
Power Rating: 720 Volt Amp at 120/240 Volt AC (Pilot Duty, NO), 290 Volt Amp at 120 Volt AC (Pilot Duty, NC), 360 Volt Amp at 240 Volt AC (Pilot Duty, NC), 1 HP at 120 Volt AC (Motor, NO), 1/4 HP at 120 Volt AC (Motor, NC), 2 HP at 240 Volt AC (Motor, NO), 1/2 HP at 240 Volt AC (Motor, NC)
Reserve Power: Super Capacitor 7 Days
Operating Temperature: -31 to 131 Deg F
Enclosure: NEMA 3R
Material: Noryl Enclosure
Mounting: Screw
Size: 5 Inch Length x 4.5 Inch Width x 9.125 Inch Height
Application: Open Office Zoning, Hallway, Meeting and Sales Area, Stock Room and Warehouse, Signage and Store Window, Security, Parking Lot
Approval: UL (Canada and US)
