Edison's SEC type fuses are UL Class G and provide fast-acting (1/2-6 A) and time-delay (7-60 A) characteristics for circuit protection needs. SEC fuses are size rejecting in terms of their overall length thereby aiding in the prevention of overfusing. Provides cost effective branch circuit fusing for systems with high short-circuit current levels present

Specifications:

Type: Class G
Characteristics: Time Lag
Voltage Rating: 600 VAC
Current Rating: 6 Ampere
Interrupting Rating: 100 Kiloampere (Symmetrical)
Terminal Type: Ferrule
Diameter: 0.41 Inch
Length: 1.31 Inch
Approval: UL, CSA C22.2
