The revolutionary BussmannTM series Low-PeakTM CUBEFuseTM delivers the smallest footprint compared to any Class CC, J or RK fuse solution — requiring up to 70% less space when combined with its unique fuse holder or UL 98 Listed Compact Circuit Protector switch. Freeing up space is powerful. And the CUBEFuse does just that, while packing up to a 300 kA interrupting rating and enabling higher equipment short-circuit current rating (SCCR). Available from 1 to 400 amps.

Specifications:

Type: Compact
Voltage Rating: 600 Volt AC, 125 Volt DC
Maximum AC Voltage Rating: 600 Volt
Maximum DC Voltage Rating: 125 Volt
Current Rating: 20 Amp
Number of Poles: 1
Starter Size: NEMA 1
Terminal Type: Lug
Size: 20 Inch Width x 5-3/4 Inch Depth
Approval: UL, CSA, CE
