Three Contact Settings Two Channel Factory Default Operates with Two Independent SPST Contacts; Double Pole Option Software Allows Option for Single Channel DPST Setting; Momentary Option for Mechanically Held Contractors Configure with Simple Jumper Change for Single Channel Momentary Operation; Enhanced Switching Inrush Current Limiting Technology Protects Relay Contacts for Extended Life with Zero Cross Switching; Rated for LED Lighting Drivers and Electronic Ballasts; Auto-Voltage Detection One Unit Covers All Voltages from 120 Volt AC to 277 Volt AC without Dip Switch to Set; Daylight Saving Automatic Adjustment; Leap Year Automatic Compensation; Manual Override Until the Next Regularly Scheduled ON or OFF, Automatic Operation then Resumes; Power Outage Backup Permanent Schedule Retention

Specifications:

Type: Astronomic
Maximum Number of Operations: 7 per Day
Number of Circuits: 2
Switch Type: SPST
Current Rating: 30 Amp (Resistive/Ballast), 15 Amp (Electronic Ballast/LED/Tungsten)
Voltage Rating: 120 to 277 Volt AC 50/60 Hertz
Power Rating: 1 HP
Operating Temperature: -40 to +149 Deg F
Enclosure: NEMA 3R
Material: Polycarbonate
Mounting: Screw Mount
Application: Outdoor Signs, Lighting Security, Heating and Air Conditioning
Approval: UL (Canada and US)
