Higher Temperature Rated Conductor Permitted with Appropriate Derating; Splicer Blocks Allow for Increasing or Decreasing Wire Size within a Circuit to Accommodate Different Connection from the Power Source to the Branch Load; RoHS Compliant

Specifications:

Type: Barrier, Splicer
Voltage Rating: 600 Volt AC/DC
Current Rating: 150 Amp
Number of Poles: 2
Number of Primary Openings per Pole: 1
Primary Opening Wire Size: 3 to 1/0 AWG Copper (Stranded), 6 to 4 AWG Copper (Stranded), 8 AWG Copper (Stranded), 14 to 10 AWG Copper (Stranded)
Number of Secondary Openings per Pole: 1
Secondary Opening Wire Size: 3 to 1/0 AWG Copper (Stranded), 6 to 4 AWG Copper (Stranded), 8 AWG Copper (Stranded), 14 to 10 AWG Copper (Stranded)
Conductor Material: Copper, Aluminum
Temperature Rating: 75 Deg C
Connector Material: Tin-Plated Aluminum
Color: Black
Approval: UL, CSA
