Requires up to 48% Less Enclosure Space to Help Reduce the Overall Assembly Size; Innovative Design Allows for a Significantly Smaller Package without Compromising Heat Rise Performance, Preventing Extensive Equipment Redesign; Global Acceptance with UL, CSA, IEC and RoHS for Products Sold Worldwide; Bolt-On Design Provides Design Flexibility for Installation in Fuse Blocks or Direct Mounting on Busbars; Meets JASO D622 Spec for Thermal Shock, Humidity and Vibration; Superior Current Cycling Performance Helps Withstand Demanding Applications; RoHS Compliant

Specifications:

Type: Standard, Universal
Voltage Rating: 600 Volt
Current Rating: 100 Amp
Terminal Type: 1/4 Inch-28 TPI x 1/2 Inch
Wire Size: 14 to 2/0 AWG (Copper/Aluminum)
Housing Material: Phenolic
Color: Black
Mounting: Stud
Temperature Rating: 150 Deg C
Approval: UL, CSA, CE
