Class CC Rejection Feature with Appropriate Fuse Block, Prevent Inserting Lesser Rated Supplementary Fuse; Time-Delay Compatible with Inrush Characteristic of Small Control Transformer; Current Limitation at Class CC Level Provide Maximum Component Short-Circuit Current Rating Protection; 200 Kiloamp Interrupting Rating Provide High Rating for Control Circuit Location; RoHS Compliant

Specifications:

Type: Class CC Rejection
Characteristics: Time Delay
Voltage Rating: 600 Volt AC
Current Rating: 5-6/10 Amp
Interrupting Rating: 200 Kiloamp (Symmetrical)
Terminal Type: Ferrule
Diameter: 13/32 Inch
Length: 1-1/2 Inch
Approval: UL 248-4, CSA, CE
