Bussmann's UL Class J fuse products extend both our Low-Peak family of products with our LPJ_SP and LPJ_SPI dual-element, time-delay fuses as well as our Limitron line offering fast-acting JKS fuses. The LPJ fuses provide industry leading 300,000 amp interrupting rating at 600Vac RMS Sym and 100kA Vdc while delivering a minimum of 10 seconds of 500% rated current ride-through performance which is ideal for sizing of high inrush loads. The LPJ products are available with optional permanent replace fuse indication. These UL Class J products in sizes 1 to 600 amps provide exceptional performance at 600 VAC and 300 VDC.

Specifications:

Type: Class J
Characteristics: Fast Acting, Time Delay
Voltage Rating: 600 VAC
Current Rating: 150 Ampere
Interrupting Rating: 200 Kiloampere RMS Symmetrical
Terminal Type: Blade
Length: 5-3/4 Inch
Approval: UL, CSA
