1-Piece Interior Removes and Reinstalls Easily; Full-Length Neutrals are Easier to Wire Reducing Installation Time and Cost; Minimum 100% Neutral Terminations; Sturdy Copper Bus and Galvanized Box Increase Durability and Reliability; Main Breaker Configuration Allows Top or Bottom Feed without Modification; Combination Slotted/Robertson Square-Drive Speeds Screw Wiring; 100% Rated Split Neutral on Each Side; Tie Bar May be Removed to Split Neutral/Ground

Specifications:

Type: Convertible Main
Voltage Rating: 120/240 VAC
Current Rating: 125 Ampere
Circuit Configuration: 1-Phase 3-Wire
Maximum Number of Circuits: 12
Maximum Number of Spaces: (6) 1-Pole 1 Inch THQL/(3) 2-Pole 1 Inch THQL/(12) 1-Pole 1/2 Inch THQP/(6) 2-Pole 1/2 Inch THQP
Main Breaker Type: THQL/THQP
Breaker Mounting: Plug-In
Interrupting Rating: 22 Kiloampere
Neutral Type: Split
Bus Material: Copper
Feed Location: Top/Bottom
Main Wire Size: 6 to 1 AWG (Copper/Aluminum)
Enclosure Type: NEMA 1, Indoor
Cover Type: Surface
Enclosure Size Designation: 3A
Size: 11-9/16 Inch W x 3-3/8 Inch D x 11-3/8 Inch H
Approval: UL
