Specifications:

Type: Molded Case, Thermal Magnetic
Frame Type: ND
Voltage Rating: 600 Volt AC, 500 Volt DC
Maximum AC Voltage Rating: 600 Volt
Maximum DC Voltage Rating: 500 Volt
Current Rating: 1000 Amp
Number of Poles: 3
Interrupting Rating: 65 Kiloamp at 240 Volt AC (UL 489), 50 Kiloamp at 480 Volt AC (UL 489), 25 Kiloamp at 600 Volt AC (UL 489), 25 Kiloamp at 500 Volt DC (UL 489), 65/33 Kiloamp at 220/240 Volt AC (IEC), 40/20 Kiloamp at 380/415 Volt AC (IEC)
Terminal Type: Line/Load Lug
Size: 9 Inch Width x 8.25 Inch Depth x 16 Inch Height
Approval: UL 489, IEC 947-2
