RoHS Compliant

Specifications:

Number of Poles: 3
Power Rating/Voltage: 60 Kilowatt at 230 Volt, 105 Kilowatt at 400 Volt, 181 Kilowatt at 690 Volt (AC-1), 84 Kilowatt at 400 Volt (AC-2), 50 Kilowatt at 230 Volt, 84 Kilowatt at 400 Volt, 105 Kilowatt at 500 Volt, 146 Kilowatt at 690 Volt (AC-3)
Current Rating: 185 Amp (AC-1), 150 Amp (AC-3)
Coil Voltage: 110 to 127 Volt AC at 40 to 60 Hertz, 110 to 127 Volt DC
Auxiliary Contact: 2NO-2NC
Mounting: Screw
Enclosure: IP00
Size: S6
Construction Standard: IEC
Approval: UL, CSA, CE, EAC
