Clampmatic Arc Control Hazardous Switching; NEMA Phasing; Pressure Terminal Connector; Connection Screw; Quick-Make Quick-Break; Easy Mounting; Padlocking Member; Fiber End Barrier; High Pressure Spring Reinforced Copper Fuse Clip; Voidable Cover Interloc

Specifications:

Type: Single
Voltage Rating: 600 Volt AC, 250 Volt DC
Current Rating: 200 Ampere
Power Rating: 50 HP at 480 VAC, 60 HP at 600 VAC (Standard), 125 HP at 480 VAC, 150 HP at 600 VAC (Maximum)
Number of Poles: 3
Wire Size: (1) 6 AWG to 350 KCMIL
Size: 17 Inch Width x 6-3/4 Inch Depth x 10 Inch Height
Used On: SB1/SB2 Switchboard and F1/F2 Panelboard
Approval: UL 98
