Midwest Electric Products R281C1P6H Pedestal Mount Service Equipment

Out of stock
SKU: 186818
Regular price $673.38

G90 Galvanized Steel Construction for Superior Corrosion Resistance; Durable Polyester Powder Coat Finish Resists Chipping and Fading; Door Removable for Installation Ease; All Components Factory Wired and Assembled, Reducing Installation Time; All Terminals Accept Copper or Aluminum Wire for Added Installation Flexibility; Loop-Feed Terminals for Maximum Flexibility; Single or Double Cabinet Posts for Fast and Economical Multiple Site Applications; Barriers Available for Line, Load and Meter Socket Isolation; Dead Front Construction Prevents Accidental Contact with Live Parts; Padlock Provision to Prevent Unauthorized Access


Type: Metered Ringless
Current Rating: 200 Ampere
Circuit Configuration: 1-Phase
Wire Size: 6 AWG to 350 KCMIL (Copper/Aluminum, (Line), 12 to 2 AWG (Copper/Aluminum, Ground)
Material: G90 Galvanized Steel
Finish: Durable Polyester Powder Coated
Mounting: Pedestal
Enclosure: NEMA 3R
Approval: UL
