ABB GE Industrial Solutions CR123C163A Overload Relay Heater
Couldn't load pickup availability
For use with single and polyphase motors. For continuous rated motors with a service factor of 1.15 to 1.25, select heaters from the heater table for the motor full-load amperes. This provides a maximum of 125% protection. For continuous rated motors with 1.0 service factor, multiply the full-load amperes of the motor by 0.90 and use this value to select heaters.
Specifications:
Trip Type: Class 20, Standard
Motor FLA: 1.36 to 1.57 Ampere (1-Phase 2 Heater Unit), 1.28 to 1.39 Ampere (3-Phase 3 Heater Unit)
NEMA Size: 0, 1, M-0, M-1
Mounting: Panel
Standard Package: 3
Used On: CR124C Series Overload Relay, CR1062R/CR1062S Series Manual Starter, CR340/CR341 Series Pumping Panel
