Crouse-Hinds ENP5151 Explosionproof Pin and Sleeve Plug

Made of Krydon fiberglass-reinforced polyester, Crouse-Hinds series Arktite non-metallic plugs, receptacles and connectors are used to supply power to portable electrical devices such as welders, motors, pumps and conveyors. Available in 30A, 60A and 100A, these pin and sleeve devices are ideal for use in non-hazardous areas of chemical plants, sewage treatment facilities, cement plants, pulp and paper, food processing and other industrial facilities.Arktite non-metallic pin and sleeve devices feature an innovative arc-snuffing design that enables large power loads to be disconnected under load without causing an arc flash in the area

Specifications:

Voltage Rating: 125/250 Volt AC at 50 to 400 Hertz
Current Rating: 15 Amp
Number of Poles: 3
Number of Wires: 2
Minimum Cable Outer Diameter: 0.39 Inch
Maximum Cable Outer Diameter: 1.2 Inch
Material: Acrylic Painted Die-Cast Copper-Free Aluminum
Enclosure: Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group F G, Class III, NEMA 3/7B/7C/7D/9F/9G/12
Approval: UL 1010, CSA C22.2
