Overload Protection, Phase Failure Protection and Unbalance Protection; Internal Power Supply; Auxiliary Contacts 1-NO, 1-NC; Manual and Automatic Reset; Switch Position Indicator; Test Function; Stop Button; Sealable Cover; Terminal Covers for Devices with Ring Terminal Lug Connection; RoHS Compliant

Specifications:

Type: Thermal
Motor FLA: 5.5 to 8 Amp
Number of Poles: 3
Trip Class: Class 10
NEMA Size: S0
Reset Type: Automatic/Manual
Ambient Temperature: Compensated
Auxiliary Contact: 1NO-1NC
Contact Rating: 690 Volt AC at 50/60 Hertz
Terminal Type: Screw
Mounting: Contactor
Enclosure: IP20
Application: 1 and 3-Phase
Approval: UL, CSA, CCC, EAC
