Allen-Bradley 100-C16J10 IEC Contactor

Common Accessories for All Contactor Sizes; Front and Side Mounting of Auxiliary Contacts; Electronic and Pneumatic Timing Modules; Space-Saving Coil-Mounted Control Modules; All Devices Can be Attached to 35 MM DIN Mounting Rail; Environmentally Friendly Materials

Specifications:

Number of Poles: 3
Power Rating/Voltage: 1 HP at 115 Volt AC 60 Hertz, 3 HP at 230 Volt AC 60 Hertz 1-Phase, 5 HP at 200/230 Volt AC 60 Hertz, 10 HP at 460 Volt AC 60 Hertz, 15 HP at 575 Volt AC 60 Hertz 3-Phase, 5.5 Kilowatt at 230 Volt AC 50 Hertz, 7.5 Kilowatt at 400/415/500/690 Volt AC 50 Hertz 3-Phase, 600 Volt (UL, CSA), 690 Volt (IEC)
Current Rating: 16 Amp (AC-3), 32 Amp (AC-1)
Coil Voltage: 24 Volt AC at 60 Hertz
Auxiliary Contact: 1NO
Mounting: 35 Millimeter DIN Rail
Enclosure: IP2X
Size: IEC 2
Construction Standard: IEC
Approval: UL 508, UL (Canada and US), CSA C22.2, CE, CCC
