ABB GE Industrial 9T51B0510 General Purpose Dry Type Transformer
Regular price
$1,377.15
Couldn't load pickup availability
The Complete Family of Transformers from GE Provide Quiet, Reliable Transformer Operation; These Transformers Can be Located Right at the Load to Provide the Correct Voltage for the Application; This Eliminates the Need for Long, Costly, Low Voltage Feeders; Encapsulated Core and Coils
Specifications:
Type Designation: QB
Construction: Encapsulated
Primary Voltage: 240 x 480 Volt AC
Secondary Voltage: 120/240 Volt AC
Frequency Rating: 50 Hertz
Power Rating: 1 Kilovolt Amp
Number of Phases: 1
Winding Type: Copper
Temperature Rise: 100 Deg C
Enclosure: NEMA 3R
Size: 7.88 Inch Width x 5.5 Inch Depth x 9.62 Inch Height
Application: Indoor/Outdoor
Weight: 30 Pound
Approval: UL, CUL
