Pass & Seymour 2097HGTRW GFCI Receptacle

  • Sale
  • Regular price $48.40
Shipping calculated at checkout.


Conducts an Automatic Test Every Three Seconds, Ensuring its Always Ready to Protect; If the Device Fails the Test the Indicator Light Flashes to Signal that the GFCI Should be Replaced; It also has Our Proven SafeLock Protection Feature - If Critical Components are Damaged and Protection is Lost, Power to the Receptacle is Disconnected; Auto-Ground Clip Assures a Positive Ground to Metal Box; Feed-Thru Wiring Configuration Allows GFCI to Protect Downstream Receptacles; Prevents Line-Load Reversal Miswire - No Power to the Face or Downstream Receptacles if Wired Incorrectly; Trip Indicator Light (Red LED); Two Back Wire Holes Per Terminal; Ground Screw has a Back Wire Clamp for Easy Installation; Mounting Screws are Shipped Captive in the Device and Wallplate for Easier Installation; Extra-Long Strap; Button Colors Match the Device Face; Dual-Direction Test and Reset Buttons; Class a Rated GFCI; Supplied with Matching TP26 Nylon Wallplate; Tri-Drive Screws

Specifications:

Type: Duplex Feed Through, Straight Blade
Configuration: NEMA 5-20R
Voltage Rating: 125 VAC at 60 Hz
Current Rating: 20 Ampere
Number of Poles: 2
Number of Wires: 3
Material: High Impact Resistant Thermoplastic
Color: White
Wiring: Back
Grade: Hospital
Approval: UL 498, UL (Canada and US), CSA
