Hammond Power Solutions Q005ERCF Buck Boost Transformer

The HPS Universal line of buck-boost transformers represent an economical way to both raise supply voltage caused by line drop or equipment demand on the distribution system; or lower voltage caused by increased system voltages due to supply line adjustments. Some loads including lighting and resistive loads, require a stable supply to maintain performance. The detrimental effects of incorrect supply line voltage can cause equipment failure.

Specifications:

Power Rating: 5 KVA
Construction: Encapsulated
Primary Voltage: 120/240 V
Secondary Voltage: 12/24 V
Frequency Rating: 50/60 Hz
Number of Phases: 1
Winding Type: Copper
Temperature Rise: 115 Deg C
Enclosure: NEMA 3R
Size: 10 Inch W x 7.75 Inch D x 17.25 Inch H
Application: Supplying Machine Tool Circuit, Actuating Relay/Bell/Signal/Alarm System, Operating Small Motor/Valve/Damper, Industrial Lighting, Circuit Isolation, Pool, Spa
