RoHS/Reach/WEEE Compliant

Specifications:

Type: Thermal
Motor FLA: 28 to 40 Amp
Number of Poles: 3
Trip Class: Class 10
NEMA Size: S2
Reset Type: Automatic/Manual
Ambient Temperature: Compensated
Auxiliary Contact: 1NO-1NC
Contact Rating: 690 Volt AC
Terminal Type: Screw
Mounting: Contactor
Enclosure: IP20
Application: 3-Phase
Approval: UL, CSA, CE, CCC, ATEX, ABS, IECEx, EAC, LRS, RINA, RMRS
