Horizontal or Vertical Mounting on Upright Panel for Application Freedom; Screw Type Power Terminals have Captive, Backed-Out Self-Lifting Pressure Plates with Screws—Reduced Wiring Time; Accessible Terminals for Easy Wiring. Optional Fingerproof Shields Available to Prevent Electrical Shock; Top Located Coil Terminals Convenient and Readily Accessible. 45 MM Contactor Magnet Coils have Three Terminals, Permitting Either Top or Diagonal Wiring—Easy to Replace European or U.S. Style Starters or Contactors without Changing Wiring Layout; Easy Coil Change and Inspectable/Replaceable Contacts

Specifications:

Type: Full Voltage, Non-Reversing
Power Rating/Voltage: 2 HP at 115 Volt 1-Phase, 3 HP at 230 Volt 1-Phase, 7-1/2 HP at 208/240 Volt 3-Phase, 10 HP at 380/480/600 Volt 3-Phase
Current Rating: 27 Amp
Phase: 1 or 3
Coil Voltage: 220 Volt AC at 50 Hertz, 240 Volt AC at 60 Hertz
Auxiliary Contact: 1NO
Size: NEMA 1
Enclosure Type: Open
Overloads: Bi-Metallic Ambient Compensated Overload Relay
Construction Standard: NEMA
