Rugged Construction, Reliable Performance, Continuity of Service and Ease of Maintenance are Emphasized; Available Fault Currents Higher than 10000 Amp are Likely to be Encountered, Such as in Manufacturing Plants, Mass Production Industries, and Commercial, Institution-AL and Other Large Buildings Served by Network Systems or Transformers of Higher Capacities; Voidable Dual Cover Interlocks Standard on All Heavy Duty Switches

Specifications:

Type: Fusible, Heavy Duty
Voltage Rating: 240 Volt AC, 250 Volt DC
Current Rating: 30 Amp
Power Rating: 1-1/2 HP at 240 Volt AC 1-Phase, 3 HP at 240 Volt AC 3-Phase, 5 HP at 250 Volt DC
Circuit Configuration: 1-Phase 2-Wire, 3-Phase 3-Wire
Number of Poles: 2
Fuse Type: Class H, Class K, Class R
Operator Type: Insulating Grip
Conductor Material: Copper/Aluminum
Conductor Size: 14 to 6 AWG
Enclosure Material: Steel
Enclosure Type: NEMA 1
Terminal Type: Lug
Size: 6.64 Inch Width x 5.05 Inch Depth x 14.26 Inch Height
Approval: UL
