Schneider Electric LC1D32G7 Motor Control Contactor

RoHS/REACH Compliant; Mercury-Free; PVC-Free; Toxic Heavy Metal Free; Green Premium Product

Specifications:

Type: Non-Reversing
Number of Poles: 3
Power Rating/Voltage: 2 HP at 115/120 Volt AC 50/60 Hertz, 5 HP at 230/240 Volt AC 50/60 Hertz 1-Phase, 10 HP at 200/208/220/240 Volt AC 50/60 Hertz, 20 HP at 460/480 Volt AC 50/60 Hertz, 30 HP at 575/600 Volt AC 50/60 Hertz 3-Phase, 7.5 Kilowatt at 220/230 Volt AC 50/60 Hertz, 15 Kilowatt at 380/400/415/440 Volt AC 50/60 Hertz, 18.5 Kilowatt at 500/660/690 Volt AC 50/60 Hertz 3-Phase
Current Rating: 32 Amp at 440/600 Volt AC (AC-3), 50 Amp at 440 Volt AC (AC-1)
Coil Voltage: 120 Volt AC at 50/60 Hertz
Auxiliary Contact: 1NO-1NC
Mounting: Clip On 35 Millimeter DIN Rail/Screw
Enclosure: Open
Construction Standard: IEC
Approval: UL 508, CSA C22.2, CE, GL, GOST, RINA
