Pass & Seymour 2624W Decorator Switch

  • Sale
  • Regular price $63.36
  • 3 available
Shipping calculated at checkout.


Impact-Resistant Polycarb Back Body and Frame; Cushioned Thermoplastic Paddle Assures Smooth, Quiet, Long Term Operation; Unique Single Rocking Butterfly Contact Provides Long Term Consistent Performance with Significantly Fewer Moving Parts; Internal Screw-Pressure-Plate Back and Side Wire Capability for Easy Installation with #14 - #10 Stranded or Solid Copper/Copper Clad Wire; Terminals Made of High Conductivity Brass and Serrated for Maximum Wire Gripping; Silver Alloy Contacts Integrally Formed to the Butterfly Actuator Assures Reliable Performance; Integral Auto-Ground Clip for Positive Ground to Metal Boxes; Tri-Drive Ground, Terminal and Mounting Screws; All Terminal Screws Backed Out, Ready-To-Install

Specifications:

Type: Standard Rocker
Voltage Rating: 120/277 VAC
Current Rating: 20 Ampere
Operation Type: 4-Way
Wiring: Back, Side
Wall Plate Included: No
Material: Impact Resistant Polycarbonate Back Body and Frame
Color: White
Size: 1.3 Inch W x 1.06 Inch D x 4.2 Inch H
Approval: UL 20, CSA C22.2
