The recommended motor circuit protectors (Siemens ETI instantaneous only circuit breakers) listed have continuous-current ratings of at least 115% of motor full-load currents. The trip-setting positions are approximately 11 times motor full-load currents. The suggested trip settings may have to beadjusted upward to no higher than 1300% of full-load current for non-design E type motors, and no greater than 1700% of full load current for design E motors, to allow for motor start-up due to inrush currents.

Specifications:

Type: Magnetic
Voltage Rating: 600 Volt AC, 250 Volt DC
Maximum AC Voltage Rating: 600 Volt
Maximum DC Voltage Rating: 250 Volt
Current Rating: 250 Amp
Number of Poles: 3
Trip Setting: 1110 to 2500 Amp
Approval: UL 489
