Scheduling 128 Time Based Events Allow Individual Programs for Each Day of the Week at a Minimum 1 Minute Apart; Event Types Include On, Off, Duration or Duty Cycle; Sensor Event 32 Sensor Driven Events Allow Individual Programs for Each Day of the Week; Pulse/Time Duration 4 Different on Settings from 1 Second to 23 Hours, 59 Minutes, 59 Seconds; Duty Cycle 4 Different on and Off Patterns from 1 Second to 23 Hours, 59 Minutes, 59 Seconds; Daylight Saving Automatic Adjustment; Leap Year Automatic Compensation; Remote Override Universal Input May be Programmed for Timed Override from a Momentary or Maintained Dry Contact Switch; Manual Override Keyboard Button Control Until the Next Regularly Scheduled ON or OFF, Automatic Operation then Resumes; Clock Format; Power Outage Backup the Program and Time of Day are Maintained for a Minimum of 2 Days by Means of a Capacitor; After Two Days a Lithium Battery Takes Over and Provides a Minimum Accumulated Time of 1 Year; The Lithium Battery Should Provide Over 10 Years of Protection

Specifications:

Number of Circuits: 12
Switch Type: SPDT
Material: Steel
Enclosure: NEMA 1
Size: 14-1/2 Inch W x 6 Inch D x 16-1/8 Inch H
Application: HVAC Equipment, Indoor/Outdoor Lighting, Meets Indoor/Outdoor Lighting Energy Code Requirements
Approval: UL (Canada and US)
