Enclosures are Intended for Outdoor Use Primarily to Provide a Degree of Protection against Falling Rain and Sleet and Must Remain Undamaged by the Formation of Ice on the Enclosure they are not Intended to Provide Protection Against Conditions Such as Dust, Internal Condensation, or Internal Icing; General Duty Switches are Intended for Applications where Reliable Performance and Continuity of Service are Needed

Specifications:

Type: Fusible, General Duty
Voltage Rating: 240 Volt AC, 250 Volt DC
Current Rating: 400 Amp
Power Rating: 15 HP at 240 Volt AC 1-Phase, 50 HP at 240 Volt AC 3-Phase, 50 HP at 250 Volt DC
Circuit Configuration: 1-Phase 2-Wire, 3-Phase 3-Wire
Number of Poles: 3
Fuse Type: Class H, Class K, Class R
Operator Type: Padlock-Off Handle
Conductor Material: Copper/Aluminum
Conductor Size: (1) 1/0 AWG to 600 KCMIL, (2) 1/0 AWG to 500 KCMIL
Enclosure Type: NEMA 3R
Terminal Type: Lug
Size: 22.4 Inch Width x 6.94 Inch Depth x 45.32 Inch Height
Approval: UL
