Selectable Manual or Automatic Reset Operation; Class 10 or 20 Heater Packs; Load Lugs Built into Relay Base; Bimetallic, Ambient Compensated Operated, Trip Free Mechanism; Electrically Isolated NO-NC Contacts (Pull Reset button to Test); Overload Trip Indication; Shrouded or Fingerproof Terminals to Reduce Possibility of Electrical Shock

Specifications:

Type: Adjustable Trip Class, Thermal, Bi-Metallic
Motor FLA: 105 Ampere
Number of Poles: 3
Trip Class: Class 10, Class 20
NEMA Size: 3
IEC Size: L to M
Reset Type: Automatic/Manual
Ambient Temperature: Compensated
Auxiliary Contact: 1NO-1NC
Contact Rating: 600 VAC 5 Ampere (NC), 600 VAC 2.5 Ampere (NO)
Terminal Type: Line Lug, Load Lug
Mounting: Panel
Enclosure: Open
Approval: UL, CSA, CE
