Scheduling Minimum on is Setting 20 Minutes with a Minimum Off Setting of 75 Minutes; Dial Accommodates up to 12 Pairs of Trippers; Manual Override Until the Next Regularly Scheduled ON or OFF Automatic Operation then Resumes; Enclosed Motor Protects Gears for Extended Life

Specifications:

Minimum ON Time: 20 Minute
Minimum OFF Time: 75 Minute
Switch Type: SPST/DPST
Current Rating: 40 Amp (General Purpose/Resistive/Tungsten), 20 Amp (Ballast), 16 Amp (Electronic Ballast)
Voltage Rating: 120/208 to 277 Volt AC 50/60 Hertz
Power Rating: 2HP at 120 Volt AC, 5 HP at 240 Volt AC
Operating Temperature: -40 to 149 Deg F
Enclosure: NEMA 1
Material: Metal
Size: 4-11/16 Inch Length x 2-15/16 Inch Width x 7-15/16 Inch Height
Application: Lighting, Pump, Sign, Air Conditioning, Water Heater, Fan
Approval: UL (Canada and US), CSA 60730
