Scheduling Minimum on is Setting 20 Minutes with a Minimum Off Setting of 75 Minutes; Dial Accommodates up to 12 Pairs of Trippers; Manual Override Until the Next Regularly Scheduled ON or OFF Automatic Operation then Resumes; Enclosed Motor Protects Gears for Extended Life

Specifications:

Type: Mechanical, 24 Hour
Minimum ON Time: 20 Minute
Minimum OFF Time: 75 Minute
Switch Type: DPST
Current Rating: 40 Amp
Voltage Rating: 120/208 to 277 Volt AC at 60 Hertz
Power Rating: 3 Watt
Operating Temperature: -40 to 149 Deg F
Enclosure: NEMA 3
Material: Metal
Size: 4-11/16 Inch Length x 2-15/16 Inch Width x 7-15/16 Inch Height
Application: Lighting, Pump, Sign, Air Conditioning, Water Heater, Fan, Indoor/Outdoor
Approval: UL (Canada and US)
