Panduit LAMLB1000-12-3 Mechanical Connector Lug
Couldn't load pickup availability
Made from High Strength, Extruded Aluminum Alloy to Provide Premium Electrical and Mechanical Performance; Tin-Plated to Inhibit Corrosion; Compact Design Saves Space; Wide Wire Range Taking Capability Minimizes Inventory Requirements; Inspection Window to Visually Assure Full Conductor Insertion; Plated Steel or Aluminum Set Screw Provides High Strength, Durable Electrical Contact between Conductor and Connector
Specifications:
Type: Single Barrel
Number of Conductors: 1
Minimum Conductor Size: 500 KCMIL
Maximum Conductor Size: 1000 KCMIL
Conductor Material: Aluminum/Copper
Screw Type: 1/2 Inch Hex Socket
Material: Tin Plated Extruded Aluminum Alloy
Number of Pad Holes: 2
Pad Size: 3.44 Inch L x 1.63 Inch W x 0.56 Inch Thk
Stud Size: 1/2 Inch
Overall Length: 6.19 Inch
Approval: UL, CSA
