Burndy YCHC2TC2 Compression Tap Connector

Wide Range of Run/Tap Combinations Including Class B Code I and Locomotive Flexible Conductor Combinations; All (B/B, B/I, I/I) Combinations are Recommended; Each Connector Accommodates Many Cable Combinations, Allowing Maximum Flexibility for the Design and Installation of a System; Color-Coded on the Connector that Matches the Die Provides Matched System for Fast and Easy Installation; Flame Retardant Type CF-FR Covers Meet Oxygen Index 28 and UL 94 V-O Requirements; A Complete Insulated UL Listed Installation is Provided; Die Index Embossed on Connector after Completion of Crimp; Permanent Inspectability of Installed Connector is Insure Consistently Reliable and Dependable Connections; RoHS Compliant

Specifications:

Shape: C
Number of Taps: 2
Conductor Material: Copper
Minimum Run Conductor Size: 8 AWG (Flex), 6 AWG Solid/Stranded
Maximum Run Conductor Size: 2 AWG (Flex), 2 AWG Solid/Stranded
Minimum Tap Conductor Size: 14 AWG (TAP2), 14 AWG (Flex, TAP2), 8 AWG (Flex, TAP1), 6 AWG Solid/Stranded (TAP1)
Maximum Tap Conductor Size: 8 AWG (TAP2), 8 AWG (Flex, TAP2), 2 AWG (Flex, TAP1), 2 AWG Solid/Stranded (TAP1)
Die Index: C
Body Material: Tin Electro Plated Copper
Approval: UL, CSA
