Cutler-Hammer AN56GN0AB NEMA Starter

Reducing the Number of Different Contactor/Overload Relay Combinations that have to be Stocked; Straight-Through Wiring Line Lugs at Top, Load Lugs at Bottom; Horizontal or Vertical Mounting on Upright Panel for Application Freedom; Screw Type Power Terminals have Captive, Backed-Out Self-Lifting Pressure Plates with +/-Screws Reduced Wiring Time

Specifications:

Type: Full Voltage, Reversing
Power Rating/Voltage: 3 HP at 115 Volt 1-Phase, 7-1/2 HP at 230 Volt 1-Phase, 10 HP at 208 Volt 3-Phase, 15 HP 240 Volt 3-Phase, 25 HP at 380 Volt AC 50 Hertz/480/600 Volt 3-Phase
Current Rating: 45 Amp
Phase: 1 or 3
Coil Voltage: 110 Volt AC at 50 Hertz, 120 Volt AC at 60 Hertz
Size: NEMA 2
Enclosure Type: Open
Overloads: Bi-Metallic Ambient Compensated Overload Relay
Construction Standard: NEMA
