Burndy YA29L2 Compression Terminal

Out of stock
SKU: 230107
Regular price $17.14

Inspection Window Allows for Visual Verification that the Wire has been Fully Inserted Prior to Crimping the Lug; Barrel is Designed with an Internal Chamfer at the Wire Entry to Ensure Smooth Insertion of the Wire, Preventing Possible Damaging of the Strands; Connectors are Clearly Marked with Stamping and Barrel Color Coding; Short/Standard Length Barrel is Recommended for Installations with Limited Space Requirement


Voltage Rating: 600 V to 35 kV
Conductor Material: Copper
Conductor Size: 250 (Navy), 250 KCMIL Stranded (Code)
Barrel Type: Short, Skived, Standard, Straight
Barrel Length: 1.06 Inch
Pad Size: 1.11 Inch W x 0.16 Inch Thk
Number of Pad Holes: 1
Stud Size: 1/4 Inch
Color: Yellow
Die Index: 16
Material: Electro-Tin Plated Copper
Overall Length: 2.17 Inch
Approval: UL 467, CSA
