Burndy QB28 Mechanical Cable Terminal Lug
Regular price
$105.66
Couldn't load pickup availability
Compact, High Copper Alloy Side Entrance Terminal for Joining a Range of Cable at Right Angles to Terminal Blocks; 1-Wrench Installation; RoHS Compliant
Specifications:
Type: Side Entry
Number of Conductors: 1
Minimum Conductor Size: 3/0 AWG Stranded
Maximum Conductor Size: 4/0 AWG Stranded
Conductor Material: Copper
Screw Type: Stud Hex Nut
Material: Copper Alloy
Number of Pad Holes: 1
Pad Size: 1.06 Inch L x 1 Inch W x 0.25 Inch Thk
Stud Size: 3/8 Inch
Overall Length: 2.06 Inch
Approval: UL 468-A, UL 468-B
