Terminal Numbering in Accordance with EN 50005 and EN 50011; Terminals Protected Against Accidental Contact in Accordance with VDE 0106 T.100, VBG4; Three Coil Terminals; Facility to Mount Side and/or Front Instantaneous Contact Blocks, Timed Auxiliary Contacts, Mechanical Latch, Voltage Suppressor Blocks and Interface Modules

Specifications:

Type: AC Operated
Coil Voltage: 110 VAC at 50 Hz, 120 VAC at 60 Hz
Contact Voltage Rating: 690 V (AC15), 440 V (DC13)
Contact Current Rating: 2 Ampere at 690 V (AC15), 0.35 Ampere at 440 V (DC13)
Contact Configuration: 4NO
Terminal Type: Screw
Mounting: 35 MM DIN Rail
Enclosure: IP20
Applicable Standard: BS 4794, IEC/EN 60947-5-1, IEC/EN 60947-1, VDE 0660
Approval: UL (Canada and US), CE, DEMKO, FI, NEMKO, SEMKO
