Automatic Operation; Manual Override Until the Next Regularly Scheduled ON or OFF Automatic Operation then Resumes; Enclosure Motor Protects Gears to Extend Life

Specifications:

Type: Mechanical, 24 Hour
Minimum ON Time: 20 Minute
Minimum OFF Time: 75 Minute
Switch Type: SPST
Current Rating: 40 Amp
Voltage Rating: 120 Volt AC at 60 Hertz
Power Rating: 3 Watt
Operating Temperature: -40 to 165 Deg F
Enclosure: NEMA 1
Material: Metal
Mounting: Screw Mount
Size: 4.687 Inch Length x 2.937 Inch Width x 7.937 Inch Height
Application: Lighting, Pump, Sign, Air Conditioning, Water Heater, Fan Control, Indoor
Approval: UL (Canada and US), CSA
