O-Z/Gedney cable supports are used to support cables in vertical raceways or risers. Properly designed cable supports must not only be capable of supporting a given weight of cable with a good margin of safety but must also support the cable without damaging the insulation or excessively reducing the amount of insulation over the conductor in the area where the cable is supported. O-Z/Gedney has been furnishing Cable Supports to the electrical industry for almost 100 years that meet these requirements.

Specifications:

Type: Knurled/Tapered
Plug Type: 1-Piece
Conduit Type: Rigid/IMC
Voltage Rating: 600 V
Conduit Position: Vertical
Conductor Size: 18 to 8 AWG, 6 to 0 AWG, 2/0 to 4/0 AWG, 4/0 AWG to 750 KCMIL (Aluminum/Copper)
Conduit Size: 4 Inch
Cable Type: Non-Armored
Material: Malleable/Ductile Iron
Application: Commercial, Indoor
Approval: UL 514B, CSA C22.2
