Specifications:

Type: Molded Case, Thermal Magnetic
Frame Type: FD
Voltage Rating: 600 Volt AC, 500 Volt DC
Maximum AC Voltage Rating: 600 Volt
Maximum DC Voltage Rating: 500 Volt
Current Rating: 200 Amp at 40 Deg C
Number of Poles: 3
Interrupting Rating: 65 Kiloamp at 240 Volt AC, 35 Kiloamp at 480 Volt AC, 22 Kiloamp at 600 Volt AC 18 Kiloamp at 500 Volt DC (UL), 65 Kiloamp at 220/240 Volt AC, 35 Kiloamp at 380/415 Volt AC (IEC)
Terminal Type: Line and Load Lug
Size: 4.5 Inch Width x 5.25 Inch Depth x 9.5 Inch Height
Approval: UL 489
